O P T I O N A L A C C E S S O R I E S
Dual Fan
Version 3 Motorcycle Dynamometer Installation Guide
3-17
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DUAL FAN
The dual fan supplies air to cool the bike’s engine. This section will walk you through
the fan installation procedures and adjusting the extension arm assembly when a
power carriage is installed.
The fan extension arm assembly comes ready to mount to the tire carriage on the
dyno. However, if you have a power carriage installed on your dynamometer, you will
need to make adjustments to the extension arm assembly before mounting the
assembly to the dyno. Refer to “Modifying the Extension Arm Assembly (For Power
Carriage Only)” on page 3-22.
To prevent possible injury, disconnect the battery before performing any dyno
maintenance or installing any optional accessory.
P ARTS L IST
The following table lists all of the parts included in the Dual Fan Installation kit.
Check your kit against the parts listed to make sure you have received all of the parts.
If any part is missing, contact Dynojet Technical Support.
part number description quantity
76722001
Or
76722002 Dual Fan Assembly (complete assembly)
Or
Dual Fan Assembly-220V (complete assembly) 1
63413002 Dual Fan Mounting Bracket and Extension Arm Assembly 1
26215520 Washer, 1.87 x 1.25 IDx .12Thk (Poly Washer) 2
36582477 Bolt, 3/8"-16 x 1-1/2", Hex 4
36488100 Nut, 3/8"-16, Nylock 4
36932100 Washer, 3/8", Splitlock, Stl 4
DE100-311 &
21629100
Outlet Box and Mounting Bracket 1
