UG034, July 1, 2014
61
Category
Signal Name
Pin on
HD1000 (U33)
Pin on SO-DIMM
Socket (J41)
VSS_45
178
VSS_46
179
VSS_47
184
VSS_48
185
VSS_49
189
VSS_50
190
VSS_51
195
VSS_52
196
Note: The pins called out as “Miscellaneous Signals” are used for communications with I
2
C master.
