58 UG034, July 1, 2014
Category Signal Name
Pin on
HD1000 (U33)
Pin on SO-DIMM
Socket (J41)
SODIMM_DQ31 M48 70
SODIMM_DM3 L49 63
SODIMM_DQS3 P49 64
SODIMM_DQS_N3 P48 62
Bank East South 3
(Byte 8)
SODIMM_DQ32 L40 129
SODIMM_DQ33 N40 131
SODIMM_DQ34 R41 141
SODIMM_DQ35 M40 143
SODIMM_DQ36 M41 130
SODIMM_DQ37 K41 132
SODIMM_DQ38 J40 140
SODIMM_DQ39 J41 142
SODIMM_DM4 R40 136
SODIMM_DQS4 P41 137
SODIMM_DQS_N4 P40 135
Bank East South 3
(Byte 9)
SODIMM_DQ40 A48 147
SODIMM_DQ41 E48 149
SODIMM_DQ42 D48 157
SODIMM_DQ43 C49 159
SODIMM_DQ44 H48 146
SODIMM_DQ45 H49 148
SODIMM_DQ46 E49 158
SODIMM_DQ47 D49 160
SODIMM_DM5 B48 153
SODIMM_DQS5 G49 154
SODIMM_DQS_N5 G48 152
Bank East South 3
(Byte 10)
SODIMM_DQ48 H51 163
SODIMM_DQ49 G50 165
SODIMM_DQ50 E50 175
SODIMM_DQ51 B49 177
SODIMM_DQ52 G51 164
SODIMM_DQ53 E51 166
SODIMM_DQ54 C50 174
SODIMM_DQ55 B50 176
SODIMM_DM6 F50 170
SODIMM_DQS6 D51 171
SODIMM_DQS_N6 D50 169
Bank East South 3
(Byte 11)
SODIMM_DQ56 H46 181
SODIMM_DQ57 G47 183
SODIMM_DQ58 E47 191
SODIMM_DQ59 H47 193
SODIMM_DQ60 C47 180
SODIMM_DQ61 B47 182
SODIMM_DQ62 B46 192
SODIMM_DQ63 E46 194
SODIMM_DM7 G46 187
SODIMM_DQS7 D47 188
SODIMM_DQS_N7 D46 186
Bank East South 2
(Byte 4)
SODIMM_CLK0 M51 101
SODIMM_CLK_N0 M50 103
Bank East South 2 SODIMM_CSN0 J47 114
