UG034, July 1, 2014 43
Signal Name Pin on HD1000 (U33)
Pin on MT44K32M18RB
(U31) (U36)
RLD_DQ15 Y4 M9
RLD_DQ16 W3 M11
RLD_DQ17 AB3 N8
RLD_DQ18 AB9 D3
RLD_DQ19 AA9 E4
RLD_DQ20 U9 C6
RLD_DQ21 Y10 C4
RLD_DQ22 AB10 C2
RLD_DQ23 W10 B5
RLD_DQ24 AA10 B3
RLD_DQ25 T10 A6
RLD_DQ26 T9 A4
RLD_DQ27 N4 J4
RLD_DQ28 L3 K3
RLD_DQ29 J4 K1
RLD_DQ30 R3 L6
RLD_DQ31 M4 L4
RLD_DQ32 J3 L2
RLD_DQ33 M3 M5
RLD_DQ34 L4 M3
RLD_DQ35 R4 N6
RLD_DQ36 P2 D11
RLD_DQ37 R2 E10
RLD_DQ38 R1 C8
RLD_DQ39 P1 C10
RLD_DQ40 N2 C12
RLD_DQ41 L2 B9
RLD_DQ42 L1 B11
RLD_DQ43 J2 A8
RLD_DQ44 K1 A10
RLD_DQ45 J5 J10
RLD_DQ46 K5 K11
RLD_DQ47 J6 K13
RLD_DQ48 P5 L8
RLD_DQ49 M6 L10
RLD_DQ50 M5 L12
RLD_DQ51 P6 M9
RLD_DQ52 N6 M11
RLD_DQ53 R5 N8
RLD_DQ54 P8 D3
RLD_DQ55 R8 E4
RLD_DQ56 P7 C6
RLD_DQ57 N8 C4
RLD_DQ58 L8 C2
RLD_DQ59 K7 B5
RLD_DQ60 J8 B3
RLD_DQ61 L7 A6
RLD_DQ62 J7 A4
RLD_DQ63 L9 J4
RLD_DQ64 J9 K3
