UG034, July 1, 2014 35
Signal Name Pin on HD1000 (U33) Pin on Connector (J3)
FMC_LA_N29 BG1 G31
FMC_LA_P30 BB4 H34
FMC_LA_N30 BC3 H35
FMC_LA_P31 BC4 G33
FMC_LA_N31 BA4 G34
FMC_LA_P32 AV3 H37
FMC_LA_N32 BB3 H38
FMC_LA_P33 AW4 G36
FMC_LA_N33 AU3 G37
FMC_HA_CC_P0 AY4 F4
FMC_HA_CC_N0 AY3 F5
FMC_HA_CC_P1 AN10 E2
FMC_HA_CC_N1 AN9 E3
FMC_HA_P2 AP10 K7
FMC_HA_N2 AK10 K8
FMC_HA_P3 AR10 J6
FMC_HA_N3 AT9 J7
FMC_HA_P4 AT10 F7
FMC_HA_N4 AM9 F8
FMC_HA_P5 AK9 E6
FMC_HA_N5 AM10 E7
FMC_HA_P6 AP8 K10
FMC_HA_N6 AR8 K11
FMC_HA_P7 AR9 J9
FMC_HA_N7 AL9 J10
FMC_HA_P8 AM8 F10
FMC_HA_N8 AM7 F11
FMC_HA_P9 AK8 E9
FMC_HA_N9 AK7 E10
FMC_HA_P10 AR6 K13
FMC_HA_N10 AM6 K14
FMC_HA_P11 AN8 J12
FMC_HA_N11 AN7 J13
FMC_HA_P12 AM5 F13
FMC_HA_N12 AK5 F14
FMC_HA_P13 AP6 E12
FMC_HA_N13 AK6 E13
FMC_HA_P14 AU4 J15
FMC_HA_N14 AW3 J16
FMC_HA_P15 AR5 F16
FMC_HA_N15 AL5 F17
FMC_HA_P16 AL7 E15
FMC_HA_N16 AT8 E16
FMC_HA_CC_P17 AN6 K16
FMC_HA_CC_N17 AN5 K17
FMC_HA_P18 AR7 J18
FMC_HA_N18 AT7 J19
FMC_HA_P19 AT6 F19
FMC_HA_N19 AT5 F20
FMC_HA_P20 AE4 E18
