UG034, July 1, 2014 57
Appendix A
– HD1000 Pins and their
connections to the SO-DIMM Socket
Table 25: ACX-BRD-HD1000-100G SO-DIMM Socket Pins and their Connections
Category Signal Name
Pin on
HD1000 (U33)
Pin on SO-DIMM
Socket (J41)
Bank East South 1
(Byte 0)
SODIMM_DQ0 Y40 5
SODIMM_DQ1 AA40 7
SODIMM_DQ2 AB40 15
SODIMM_DQ3 V41 17
SODIMM_DQ4 AB41 4
SODIMM_DQ5 AA41 6
SODIMM_DQ6 T41 16
SODIMM_DQ7 U41 18
SODIMM_DM0 T40 11
SODIMM_DQS0 W41 12
SODIMM_DQS_N0 W40 10
Bank East South 1
(Byte 1)
SODIMM_DQ8 U49 21
SODIMM_DQ9 Y48 23
SODIMM_DQ10 T49 33
SODIMM_DQ11 V49 35
SODIMM_DQ12 AB49 22
SODIMM_DQ13 AB48 24
SODIMM_DQ14 W49 34
SODIMM_DQ15 W48 36
SODIMM_DM1 T48 28
SODIMM_DQS1 AA49 29
SODIMM_DQS_N1 AA48 27
Bank East South 1
(Byte 2)
SODIMM_DQ16 T43 39
SODIMM_DQ17 AB42 41
SODIMM_DQ18 AA42 51
SODIMM_DQ19 T42 53
SODIMM_DQ20 AB43 40
SODIMM_DQ21 AA43 42
SODIMM_DQ22 Y42 50
SODIMM_DQ23 W42 52
SODIMM_DM2 U43 46
SODIMM_DQS2 V43 47
SODIMM_DQS_N2 V42 45
Bank East South 1
(Byte 3)
SODIMM_DQ24 J49 57
SODIMM_DQ25 N48 59
SODIMM_DQ26 M49 67
SODIMM_DQ27 R49 69
SODIMM_DQ28 L48 56
SODIMM_DQ29 J48 58
SODIMM_DQ30 R48 68
