ACX-BRD-HD1000-100G Development Board Interfaces
Figure 10 shows the interfaces available on the development board. These interfaces are
discussed in more detail in the following sections:
Networking and Communications Interfaces
System Interfaces
Controller Interfaces
Memory Interfaces
User Interfaces
Figure 10: ACX-BRD-HD1000-100G Development Board Interface Overview
