44 UG034, July 1, 2014
Signal Name Pin on HD1000 (U33)
Pin on MT44K32M18RB
(U31) (U36)
RLD_DQ65 R10 K1
RLD_DQ66 M9 L6
RLD_DQ67 M10 L4
RLD_DQ68 J10 L2
RLD_DQ69 K9 M5
RLD_DQ70 L10 M3
RLD_DQ71 N10 N6
RLD_A0 M11 E2 E2
RLD_A1 M12 F5 F5
RLD_A2 K11 F4 F4
RLD_A3 R11 F9 F9
RLD_A4 J12 F10 F10
RLD_A5 L12 F12 F12
RLD_A6 N12 G3 G3
RLD_A7 J11 F1 F1
RLD_A8 R12 G11 G11
RLD_A9 C3 F13 F13
RLD_A10 E3 H13 H13
RLD_A11 H3 D1 D1
RLD_A12 H4 H11 H11
RLD_A13 D4 D13 D13
RLD_A14 D3 H3 H3
RLD_A15 E4 G2 G2
RLD_A16 A4 H4 H4
RLD_A17 B4 H10 H10
RLD_A18 F4 G12 G12
RLD_A19 H1 H1 H1
RLD_A20 B2 F2 F2
RLD_BA0 G7 G9 G9
RLD_BA1 C7 G5 G5
RLD_BA2 E7 H8 H8
RLD_BA3 E8 H6 H6
RLD_CK D7 H7 H7
RLD_CK_N D8 G7 G7
RLD_CS_N H7 E12 E12
RLD_REF_N B7 F8 F8
RLD_WE_N G8 F6 F6
RLD_RESET_N H8 A13 A13
RLD_QVLD0 E6 J12
RLD_QVLD1 H5 J2
RLD_QVLD2 B5 J12
RLD_QVLD3 G5 J2
RLD_TDI N10 N10
RLD_TDO N4 N4
RLD_TMS N12 N12
RLD_TCK N2 N2
RLD_DM0 V12 B7
RLD_DM1 V4 M7
RLD_QK0 W11 D9
RLD_QK0_N W12 E8
