Dell POWEREDGE C6105 User Manual
Page 78
78
|
Using the System Setup Program
Token Setup option
Description
5123
VT-UTF8 Combo
Key Support
Disable VT-UTF8 Combination Key Support for
ANSI/VT100 terminals.
5124
VT-UTF8 Combo
Key Support
Enable VT-UTF8 Combination Key Support for
ANSI/VT100 terminals
5125
CS Sparing Enable
Not reserve a spare memory rank in each channel.
5126
CS Sparing Enable
Reserve a spare memory rank in each channel.
The IPMI command table
IPMI command
Setup option
Description
ipmitool raw 0x34 0x78 1
PSU Power Capping The setting controls PSU Power, its
range limited in 150˜2000W. The
value will send to BMC by IPMI
command and BMC will control
PSU power. This setting only can
be seen when ―Power
Management‖ be selected to
―APML‖ mode and the system
board at location 4 in the chassis.
ipmitool raw 0xc 1 1 3
IP Address
Uses this option to input BMC
LAN port IP address.
ipmitool raw 0xc 1 1 6
Subnet Mask
Uses this option to input BMC
LAN port subnet mask address.
ipmitool raw 0xc 1 1 12
GateWay Address
Uses this option to input BMC
LAN port Gateway address.
