174 | Installing System Components
Figure 3-55. Removing and Installing a Front Panel
1 front-panel assembly 2 front panel
3 retention hooks
Installing the Front Panel
CAUTION: Many repairs may only be done by a certified service technician. You
should only perform troubleshooting and simple repairs as authorized in your
product documentation, or as directed by the online or telephone service and
support team. Damage due to servicing that is not authorized by Dell is not
covered by your warranty. Read and follow the safety instructions that came with
the product.
1 Push aside the retention hooks on the front-panel assembly and place
the front panel into the front-panel assembly. See Figure 3-55.
2 Replace the front-panel assembly into the hard-drive cage. See Figure
3-54.
3 Replace the screws that secure the front-panel assembly to the hard-
drive cage. See Figure 3-54.
