76 YP3010HDP/3020P/3025 Table of Contents Index Great Plains Manufacturing, Inc.
401-703M Table of Contents Index 2013-09-09
10HD, 25P Meter Wheel Replacement
Note: Applies only to 10HD and 25P Series openers.
See page 80 for 20P Series.
Choose the correct seed meter wheel for the type of
seed you will be using. Be sure to use the same wheel
type on all meters.
Meter Wheels Not Interchangeable:
Seed meter wheels for the 10HD and 25P Series row units are
made of a green color material and are not interchangeable
with the other Great Plains seed meter wheels, such as Black
for 20P Series. Use only green wheels in 10HD and 25P Series
row units.
1. Clean out meter. For more information, see “10HD,
25P Meter Removal” on page 74.
Refer to Figure 100
2.
Push in spring-loaded wheel retainer and make
1 ⁄
4
turn. Pull off wheel retainer and spring.
Refer to Figure 101
3.
Pry the seed meter wheel out about
1 ⁄
4
inch (6 mm)
using the tool stored under the walkboard, and spin
backward to clean out seeds from top pockets.
Note: If wheel is not free of all seed, wheel removal is
much more difficult, as pocketed seeds will shear
against meter parts.
Refer to Figure 102
4.
Remove seed meter wheel.
Figure 100: 10HD, 25P:
Singulator Wheel Retainer
22911
Figure 101: 10HD, 25P:
Pry Meter Wheel
22913
Figure 102: 10HD, 25P:
Remove Wheel
25274
