126 YP3010HDP/3020P/3025 Table of Contents Index Great Plains Manufacturing, Inc.
401-703M Table of Contents Index 2013-09-09
GPS Receivers
See
www.trimble.com for complete GPS receiver specifi-
cation and other technical data.
AgGPS 162
This is a GPS L1 receiver with SABS augmentation
(WAAS, EGNOS or MSAS). It provides
±8-12in
pass-to-pass DGPS accuracy, at 1, 5 or 10Hz position
update rates. 467980458 cable on page 125 provides
interface. Mount is magnetic or one
5 ⁄
8
in bolt.
This economy receiver may be preferred where
auto-steer and Swath Command™ are not installed.
AgGPS 262
This is a GPS L1 and L2 receiver with C/A code and car-
rier phase measurement, L-band DGPS. It provide pass
accuracies of:
±1in RTK (requires AgGPS 900 radio for corrections)
±2-4in: OmniSTAR HP
±3-5in: OmniSTAR XP
±6-8in: OmniSTAR VBS or WAAS
at 1, 5 or 10Hz position update rates. 467980458 cable
on page 125 provides interface. Mount is three 10mm
bolts.
This receiver is recommended for auto-steer and
Swath Command™ applications.
Row-Pro™ Servo Down-Force
This system actively controls the down-force at every
row, reacting to changing field conditions. Load cells
send force readings to the seed monitor. The seed moni-
tor operates valves supplying air to cylinders at each row.
The cylinders counteract the standard springs, providing
an adjustment range of +0/-60 pounds (+0/-27 kg). The
seed monitor console provides in-cab control of row
force, and continuous reporting and alerts.
Presently, the Row-Pro™ option is only available factory
installed (initial planter order feature code 60), and is not
field-installable.
Row-Pro™ is available only on Model YP3025 (25 Series
openers), excepting single row spacings below 35cm
(13.7in).
Description Part Number
DJ TRIMBLE AG GPS 162 RECEIVER 823-351C
DJ TRIMBLE AG GPS 262 RECEIVER 823-380C
31419
31419 AgGPS 262
AgGPS 162
31549
