Operating instructions – Great Plains YP3025 Operator Manual User Manual
Page 177
Great Plains Manufacturing, Inc.
Appendix R - Row Pro
173
2013-09-09
401-703M
Operating Instructions
Refer to Figure 167
Row-Pro™ is a factory installed option for implements
with 25 series openers that are equipped with
DICKEY-john
®
IntelliAg
®
. It provides an automatic
adjustment for more consistent down pressure. Once
the springs are set, Row-Pro™ pneumatically
adjusts/reduces pressure on the openers.
There is one cylinder
for each row located between
the parallel arms. Based on loading on the side depth
wheels, Row-Pro™ adjusts air pressure in the air cylin-
ders.
Refer to Figure 168
There is one valve set per opener section, located in the
center of the section. It allows each section to be con-
trolled independently.
Note: For twin row there are two valve sets
per section:
one for the front openers and one for the rear open-
ers.
1
Figure 167
Row-Pro™ Cylinder
32085
1
2
2
2
Figure 168
Row-Pro™ Valve Sets
32084
32088
2
