158 YP3010HDP/3020P/3025 Table of Contents Index Great Plains Manufacturing, Inc.
401-703M Table of Contents Index 2013-09-09
Seed Connections, Left, 4 of 5
24 Row: YP3025-24TR70
36 Row: YP3010HDP-3610, YP3020P-3610, YP3025-3610
Section Left Wing Left Center Capped
Air Box P01 P02 P03 P04 P05 P06 P07 P08
Ctr Guide C1 C2 C3 - - - n/c n/c
Wing Guide W1 W2 W3 - - - n/c n/c
Rack Tube T1 T2 T3 T10 T11 T12 n/c n/c
Y-Tube
Y Y Y Y Y Y
n/c n/c
Row Unit R01 R02 R03 R04 R05 R06 R07 R08 R09 R10 R11 R12 n/c n/c
Section Left Wing Left Center
Air Box P01 P02 P03 P04 P05 P06 P07 P08
Ctr Guide C1 C2 C3 C4 C5 - - -
Wing Guide W1 W2 W3 W4 W5 - - -
Rack Tube T1 T2 T3 T4 T9 T10 T11 T12
Splitter | | | |
Y Y
| |
Y-Tube
Y Y Y Y | Y | Y Y Y
Row Unit R01 R02 R03 R04 R05 R06 R07 R08 R09 R10 R11 R12 R13 R14 R15 R16 R17 R18
1
P01 P16
GUIDES
RACK
AIR BOX
RACK
31436
1 1
2 2
3
4
5
3
4
5
2 3 4
9
T10 T11
C W
T
S
Y
T
5 6 7 8
T12
1
P01 P16
GUIDES
RACK
AIR BOX
RACK
31436
1 1
2 2
3
4
5
3
4
5
2 3 4
9
T10 T11
C W
T
S
Y
T
5 6 7 8
T12
