25 Series Final Meter Drive
25P: Meter Drive (Front type)
Note: No idlers on mount.
top chain passes over single idler on shank
be sure to reconnect idler spring
25P: Meter Drive (Mid type)
Note: be sure to reconnect idler spring
top chain passes between 2 idlers at mount
top chain passes between 2 idlers at shank
25P: Meter Drive (Rear type)
Note: be sure to reconnect idler spring
top chain passes between 2 idlers at mount
top chain passes between 2 idlers at shank
