96 YP3010HDP/3020P/3025 Table of Contents Index Great Plains Manufacturing, Inc.
401-703M Table of Contents Index 2013-09-09
10HD/25P Precision Meter Clean-Out
Refer to Figure 130 (finger meter shown, but step is identical)
1.
Place a bucket or pan under meter to catch any seed
during clean-out.
2. Slide the retaining ring up and remove the seed
hose.
Refer to Figure 131
3.
Pull clean-out door away from the opening and allow
seed to fall.
4. Remove the seed meter wheel for thorough cleaning.
See “10HD, 25P Meter Removal” on page 74 for
more information.
10HD/25P Finger Meter Clean-Out
Refer to Figure 130
1.
Place a bucket or pan under meter to catch any seed
during clean-out.
2. Slide the retaining ring up and remove the seed
hose.
Refer to Figure 132
3.
Pull clean-out door away from the opening and allow
seed to fall.
Figure 130
Remove Hose Retaining Ring
22883
Figure 131
Open Clean-out Door
22885
Figure 132
Finger Meter Clean-out Door
21920
