Seed Connections, Left, 3 of 5
24 Row: YP3025-2415
24 Row: YP3025-24TR30
Section Left Wing Left Center
Air Box P01 P02 P03 P04 P05 P06 P07 P08
Ctr Guide C1 C2 C3 C4 - - - n/c
Wing Guide W1 W2 W3 W4 - - - n/c
Rack Tube T1 T2 T3 T9 T10 T11 T12 n/c
Y-Tube
Y Y Y Y Y Y Y
n/c
Row Unit R01 R02 R03 R04 R05 R06 R07 Cap R08 R09 R10 R11 R12 Cap n/c
Section Left Wing Left Center Capped
Air Box P01 P02 P03 P04 P05 P06 P07 P08
Ctr Guide C1 C2 C3 C4 - - n/c n/c
Wing Guide W1 W2 W3 W4 - - n/c n/c
Rack Tube T1 T2 T3 T9 T10 T11 n/c n/c
Y-Tube
Y Y Y Y Y Y
n/c n/c
Row Unit R01 R02 R03 R04 R05 R06 R07 R08 R09 R10 R11 R12 n/c n/c
