Tweco 400 MST Arc Master - Manual (Page 89)

2
No. DWG No. Part No. Description Additional Information QTY.
33 W7001328 Panel, Front, gen 3.1, IPS E0D006301 1
34 W7001329 Panel, Rear, gen 3.1, IPS E0D004901 1
35 W7001330 Label, Side, gen 3.1, IPS E0D005207 2
36 W7001331 Case, Front, gen 3.1, IPS E0C346000 1
37 W7001332 Board, Front, gen 3.1, IPS JEA496001 1
38 W7001333 Cover, Rear, gen 3.1, IPS JDA788900 1
39 W7001334 Cover, Protector, gen 3.1, IPS E0C299200 1
40 10-6791 Cover, Encoder, gen 3.1, IPS EBA514400 1
41 W7001336 Cover, PCB, gen 3.1, IPS E1B537600 (with Dustcover Sheet) 1
42 W7001718 Label, Name, gen 3.1, IPS N4A831400 (400MST) 1
43 W7001338 Label, Side, gen 3.1, IPS N4A785200 2
44 W7001339 Label, 1 Warning, gen 3.1, IPS N1B029700 1
45 W7001340 Label, 2 Warning, gen 3.1, IPS N1B029800 1
46 W7001341 Label, Output Terminal, gen 3.1, N4A178600 1
47 W7001342 Label, Switch, gen 3.1, IPS N4A146500 1
48 W7001343 Label, 14/19 Switch, gen 3.1, IPS N4A311800 1
49 W7001344 Label, MCB, gen 3.1, IPS N4A144200 1
50 W7001345 Label, VRD, gen 3.1, IPS N4A919100 1
51 W7001511 Label, VRD, gen 3.1, IPS N4A598700 1
52 10-6660 Terminal, Output, F, gen 3.1, IPS TRAK-BE35-70S 2
53 N/A Cable, Input, gen 3.1, IPS SOOW AWG8X4C L=3.4m 1
54 10-6795 Clamp, Input, gen 3.1, IPS EBA156800 1
55 W7001349 Heatsink, gen 3.1, IPS E1B895000 2
56 W7001350 Heatsink, gen 3.1, IPS E1B870100 1
57 W7001351 Spring Clip,IGBT, gen 3.1, IPS E1B850100 8
58 W7001352 Chassis, PCB1, gen 3.1, IPS J5B017500 1
59 W7001353 Chassis, gen 3.1, IPS J3C356600 1
60 10-6665 Knob, gen 3.1, IPS 2621603 1
61 10-6666 Knob Cap, gen 3.1, IPS 3021104 1
62 W7001356 Cover, Protector, gen 3.1, IPS N1B039200 1
63 W7001357 Sheet, Rubber, gen 3.1, IPS EDA227700 4
64 W7001358 Post, 1(M5), gen 3.1, IPS EBA643600 (M5-M5) 3
65 W7001359 Bus Bar, D, gen 3.1, IPS EDA761400 1
66 W7001360 Bus Bar, T-D, gen 3.1, IPS EDA003800 4
67 W7001361 Bus Bar, 1 D, gen 3.1, IPS EDA046900 1
68 W7001362 Bus Bar, 2 D, gen 3.1, IPS EDA047000 1
69 W7001363 Bus Bar, 3 D, gen 3.1, IPS EDA047100 1
70 W7001364 Bus Bar, 4 D, gen 3.1, IPS EDA047200 1
71 10-6868 Bus Bar, S1, gen 3.1, IPS ECA321000 3
72 W7001366 Bus Bar, Output, gen 3.1, IPS EDA761300 1
73 W7001367 Bus Bar, T-CC, gen 3.1, IPS EDA047300 1
74 W7001368 Post, Output, gen 3.1, IPS ECA867900 2
75 W7001369 Insulated Board, gen 3.1, IPS E1B872000 2
76 W7001370 Insulation Sheet, gen 3.1, IPS E1B859700 1
77 W7001371 Insulation Sheet, gen 3.1, IPS EDA079800 1
78 W7001372 Cover, Protector, gen 3.1, IPS E1B933900 1
79 W7001373 Cover, Protector, gen 3.1, IPS E1B933100 1
80 W7001374 Clip, gen 3.1, IPS #74 NATURAL 4
81 W7001375 Cover, CON1, gen 3.1, IPS 1070500-20 (with String) 1
82 10-6874 Cover, CON2, gen 3.1, IPS 97121-422R (with String) 1
83 W7001377 Edge Protect, gen 3.1, IPS EH18U 2
84 10-2020 Plug, Output, gen 3.1, IPS TRAK-SK50 1
85 300X4866 Operating Manual, gen 3.1, IPS Operating Manual 1
