APPENDIX 1 PARTS LIST
1
1
Equipment Identification
All identification numbers as described in the Introduction chapter must be furnished when ordering parts or
making inquiries. This information is usually found on the nameplate attached to the equipment. Be sure to
include any dash numbers following the Part or Assembly numbers.
2 How To Use This Parts List
The Parts List is a combination of an illustration and a corresponding list of parts which contains a break-
down of the equipment into assemblies, subassemblies, and detail parts. All parts of the equipment are listed
except for commercially available hardware, bulk items such as wire, cable, sleeving, tubing, etc., and per-
manently attached items which are soldered, riveted, or welded to other parts. The part descriptions may be
indented to show part relationships. To determine the part number, description, quantity, or application of an
item, simply locate the item in question from the illustration and refer to that item number in the correspond-
ing Parts List.
PART NUMBERS: ARC MASTER 400MST
10-3072
No. DWG No. Part No. Description Additional Information QTY.
1 CON1 W7001302 Socket, Remote, gen 3.1, IPS MS3102A20-27S (NIC) 14P (with Wiring
Assembly) 1
2 CON2 W7001303 Socket, Remote, gen 3.1, IPS MS3102A22-14S (NIC) 19P (with Wiring
Assembly) 1
3 CT1-2 W7001304 Transformer, gen 3.1, IPS F2A503001 CT 1:40 2
4 D1 10-6769 Diode, gen 3.1, IPS DFA100BA160 1
5 D2-5 10-6629 Diode, gen 3.1, IPS DBA200UA60 4
6 FAN1 W7001307 Fan, gen 3.1, IPS 109E5724H507 DC 24V 16.8W 1
7 FCH1 W7001308 Inductor, gen 3.1, IPS F3A207601 400A MIG FCH 1
8 HCT1 10-5003 Sensor, Current, gen 3.1, IPS HC-TN200V4B15M 200A 4V 1
9 L1 W7001309 Reactor, gen 3.1, IPS GP-7 1
10 MCB1 W7001310 Circuit Breaker, gen 3.1, IPS TBC5071-01-0820 1P 125V 2.5AT 1
11 MCB2 10-2235 Circuit Breaker, gen 3.1, IPS TBC5071-20-1420 1P 125V 10AT 1
12 PCB1 W7001312 PCB, gen 3.1, IPS WK-5493 U01 MAIN PCB 1
13 PCB2 W7001313 PCB, gen 3.1, IPS WK-5597 U01 LINK PCB 1
14 PCB3 W7001314 PCB, gen 3.1, IPS WK-5548 U01 DDC PCB 1
15 PCB4 10-6635 PCB, gen 3.1, IPS WK-4819 U01 DETECT PCB 1
16 PCB5 W7001315 PCB, gen 3.1, IPS WK-5696 U01 CONECT PCB 1
17 PCB6 W7001742 PCB, gen 3.1, IPS WK-5688 U03-2 MIG CTRL PCB 1
18 PCB7 W7001317 PCB, gen 3.1, IPS WK-5689 U01 FILTER PCB 1
19 PCB8-11 W7001318 PCB, gen 3.1, IPS WK-5479 U01 GATE PCB (with 4
20 PCB12 W7001744 PCB,WK5527 U15,GEN3.1,IPS WK-5527 U15 PANEL PCB 1
21 PCB13 W7001320 PCB, gen 3.1, IPS WK-5528 U01 ENCODER PCB 1
22 PCB14 W7001321 PCB, gen 3.1, IPS WK-5594 U01 TRANS PCB 1
23 PCB15 W7001322 PCB, gen 3.1, IPS WK-5606 U01 DIODE SNUBBER PCB 1
24 PCB16 10-6740 PCB, gen 3.1, IPS WK-4917 U04 INPUT FILTER PCB 1
25 PCB17 W7001323 PCB, gen 3.1, IPS WK-5699 U01 14/19 CONNECT PCB 1
26 PCB18 W7001324 PCB, gen 3.1, IPS WK-5499 U01 FILTER PCB 1
27 R2-3 W7001325 Resistor, gen 3.1, IPS MHS20A151JI 20W 150OHM 2
28 S1 10-6857 Switch, gen 3.1, IPS DCP-103SR100C-480V 3P-480V 1
29 S2 10-5222 Switch, gen 3.1, IPS SDKGA4-A-1-A 1
30 S3 10-5222 Switch, gen 3.1, IPS SDKGA4-A-1-A 1
31 T1 W7001326 Transformer, gen 3.1, IPS F3A216701 1
32 TH1, 2 10-5228 Thermistor, gen 3.1, IPS ERTA53D203 20k
Ω/25°C B=3950K
