Tweco 400 MST Arc Master User Manual
Page 41
400MST
9
ADVANCED TROUBLESHOOTING
9 – 4
1.2 Verification and Remedy to
the Indicated Error Codes
NOTE
The capacitors inside the power supply will slowly
discharged after you turn off the switch of the
power supply or the switch at the breaker box (dis-
tribution panel). Wait at least 5 minutes for the dis-
charge to complete and then remove the cases to
continue your inspection and repair (or mainte-
nance) inside the power supply. As for the removal
and installation of the case, refer to section
9.1.1.
NOTE
During the "Verification/Remedy" procedures
below, follow the alphabetical sequence (a, b, c...)
and proceed with your verification and confirma-
tion.
NOTE
After you confirm and replace all spare parts and
components, confirm that there are no damaged
harnesses or connectors, uninstalled or loose
screws.
1.2.1 E01 "Over-Temperature at the
primary side"
Cause
Occurs when an over-temperature condition of the
primary IGBT is detected.
Verification/Remedy
a) Unit may be in thermal shutdown mode.
Review the rated duty cycle of the unit per
page 2-4. Exceeding the duty cycle
can damage the unit and void the warranty.
Refer also to section 2.7 for addi-
tional information.
b) Verify the ventilating condition.
Maintain a clear and unobstructed distance
of more than 12 in. in the front and more that
20 in. in the rear of the unit for ventilation pur-
poses.
Verify and maintain clean, dust free, front and
rear airflow paths. Cleaning and removing
dust from the front and rear panels once
every six months in a normal working envi-
ronment is recommended. Extremely dusty
environments will require more frequent
cleanings.
c) Verify the operation of the cooling fan, FAN1,
and replace it if necessary.
Verify the condition of FAN1. Verify that there
are no broken or cracked fan blades and that
FAN1 is not producing any abnormal sounds.
If broken or cracked FAN1 blades, or abnor-
mal sounds are emanating from FAN1,
replace FAN1.
Refer to section 9.2.4.19 for the replacement
of FAN1.
Refer to section 9.1.4.4 for additional FAN1
tests.
Verify the operation of the cooling fan and
replace it if the condition of FAN1 is inactive.
Follow the instruction in section 9.1.4.4.
d) Replace PCB3 (WK-5548).
Refer to section 9.2.4.3 for the replacement
of PCB3.
