Manual 0-5057

6-5

PARTS LIST

PARTS LIST

PAK 200

6.05 Optional Gas Supply Leads

HOSE ASSEMBLIES

Length

(Feet)

10’

15’

25’

35’

50’

75’

100’

(Meters)

3.05

4.6

7.6

10.6

15.2

22.9

30.4

1/4”

Inert B (RH)

9-2146

9-5061

9-5073

9-5085

9-5097

9-5109

9-5121

02 B (RH)

9-9008

9-9009

9-9010

9-9011

3/8”

Inert B (RH)

Inert B (LH)

9-9012

9-9013

9-9014

9-9015

Table 6-5: Hose Assemblies

SYNFLEX HOSE FITTINGS

ID

CATALOG #

per foot

NUT

Inert B

(LH)

NUT

Inert B

(RH)

NIPPLE

Inert

NUT FUEL

B (LH)

NUT 02 B

(RH)

NIPPLE

CLAMP

1/4”

9-3743

9-3556

9-2776

9-2775

8-5518

8-5015

8-0327

8-0384

3/8”

9-3616

8-6473

N/A

N/A

N/A

8-6617

N/A

8-0384

1/2”

9-2551

8-6470

N/A

N/A

9-3831

Table 6-6: Hose Fittings

ADAPTER FITTINGS Catalog #

1/4” NPT

Inert B (RH)

8-0330

Inert B (LH)

8-0329

02 B (RH)

8-0260

1/4” Barb

8-4264

Table 6-7: Adapter Fittings
