PAK 200
OPERATION
OPERATION 4-10 Manual 0-5057
Type Torch: PCH-200
Type Material: Stainless Steel
Type Plasma Gas: Ar-35H2
Type Secondary Gas: Nitrogen
Thickness
Tip
Output
Volts
Amperage
Speed
(Per Minute)
Standoff
Plasma Gas
Press
Sec Gas Press
Total Flow (SCFH)
Pierce Height
Inches
mm
(Cat. No.)
(VDC)
(Amps) Inches Meters Inches
mm
psi
bar
psi
bar
Plasma
Secondary
Inches
mm
0.750
19.1
32-1322 140
120
20
0.5
0.19
4.8
62
4.3
60
4.1
78
340
0.40
10.2
1.000
25.4
32-1322 145
120
15
0.4
0.19
4.8
62
4.3
60
4.1
78
340
N/R N/R
1.250
31.8
32-1322 150
120
10
0.3
0.19
4.8
62
4.3
60
4.1
78
340
N/R N/R
1.500
38.1
32-1322 155
120
7
0.2
1.9
48.3
62
4.3
60
4.1
78
340
N/R N/R
0.500
12.7
32-1323
155
200
50
1.3
0.27
6.9
70
4.8
60
4.1
84
340
0.40
10.2
0.750
19.1
32-1323
160
200
30
0.8
0.3
7.6
70
4.8
60
4.1
84
340
0.50
12.7
Table 4-12: Cut Chart Stainless Steel - Ar-35H2/Nitrogen
Type Torch: PCH-200
Type Material: Aluminum
Type Plasma Gas: Ar-35H2
Type Secondary Gas: Nitrogen
Thickness
Tip
Output
Volts
Amperage
Speed
(Per Minute)
Standoff
Plasma Gas
Press
Sec Gas
Press
Total Flow (SCFH)
Pierce Height
Inches
mm
(Cat. No.)
(VDC)
(Amps)
Inches Meters Inches
mm
psi
bar
psi
bar
Plasma
Secondary
Inches
mm
0.250
6.4
32-1322 130
120
100
2.5
0.25
6.4
65
4.5
60
4.1
75
340
0.25
6.4
0.500
12.7
32-1322 135
120
60
1.5
0.25
6.4
65
4.5
60
4.1
75
340
0.38
9.7
0.750
19.1
32-1322 135
120
30
0.8
0.25
6.4
65
4.5
60
4.1
75
340
0.38
9.7
1.000
25.4
32-1322 140
120
20
0.5
0.25
6.4
65
4.5
60
4.1
75
340
N/R N/R
0.500
12.7
32-1323
145
200
110
2.8
0.3
7.6
70
4.8
60
4.1
82
340
0.40
10.2
0.750
19.1
32-1323
150
200
50
1.3
0.4
10.2
70
4.8
60
4.1
82
340
0.45
11.4
Table 4-13: Cut Chart Aluminum - Ar-35H2/Nitrogen
