SPECIFICATIONS 2-2 Manual 0-5057
PAK 200 SPECIFICATIONS
2.06 Power Supply Specifi cations & Electrical Requirements
PAK 200 Power Supply Specifi cations
Max OCV (U
0
) 380 VDC
Max Output Current 200 Amps
Output Voltage 160 VDC
Duty Cycle Rating 100% @ 200A @ 160V (32 kW)
Operating range 14°F to 122°F (-10°C to + 50°C)
Power Factor 0.70 @ 200 ADC Output
Cooling Forced Air (Class F)
Table 2-2: PAK 200 Power Supply Specifi cations
PAK-200 Power Supply
Input Power Input Current Suggested Sizes (See NOTE)
Voltage Freq. 3-Ph 3-Ph Fuse (Amps) Wire (AWG)
(Volts) (Hz) (kVA) (Amps) 3-Ph 3-Ph
208 60 47 130 160 #2 2
230 60 49 125 150 #2 2
400 50 54 77 100 #4 1
460 60 59 75 90 #4 1
Line Voltages with Suggested Circuit Protection and Wire Sizes
NOTE: Based on National Electric Code and Canadian Electrical Code
1 Extra Hard Usage Type SO, SOW, SOO, SOOW, ST, STW, STO, STOW, STOO, STOOW
2 Extra Hard Usage Type G, G-GC, W
Table 2-3: PAK 200 Power Supply
CAUTION
Fuse and wire sizes are for reference only. The installation must conform to national and local codes
for the type and method of wire being used.
