2.09 Gas Requirements
The customer will provide all gases and pressure regulators. Gases must be of high quality. Pressure regulators
shall be equipped with stainless-steel diaphragms and installed as close as possible to the Gas Console. Specify Dual
Stage Stainless diaphragm regulators for hi-pressure cylinders (> 400 inlet psi) (example: Victor VTS-450-D-500,)
Single stage Station-stainless diaphragm regulator for low pressure (< 350 inlet psi) liquid or bulk tank supply
application (example Victor # LC-350DR).
MATERIAL MILD STEEL STAINLESS STEEL ALUMINUM
OPERATION GAS TYPE GAS TYPE GAS TYPE
PLASMA SHIELD PLASMA SHIELD PLASMA SHIELD
35-200 A Cut Air Air H35 N2 H35 N2
Table 2-6: Gas Requirements
PAK-200 Power Supply: Gas Pressures, Flows, and Quality Requirements
Gas Quality Minimum Pressure Flow
N
2
(Nitrogen)
99.5% Purity
(Liquid recommended)
<1000 ppm O
2
, <32 ppm H
2
O)
80 psi
5.5 bar / 827 kPa
350 scfh (165 l/min)
Compressed
Air
Clean, Dry,
Free of Oil (see Note 1)
90 psi
6.2 bar / 621 kPa
450 scfh (212 1/min)
H35 (Argon-Hydrogen)
H35 = 35% Hydrogen,
65% Argon
99.995% Purity
(gas recommended)
90 psi
6.2 bar / 827 kPa
100 scfh (47 1/min)
H
2
O (Water) See Note 2 50 psi (3.5 bar) 10 gph (38 lph)
Note 1: The air source must be adequately fi ltered to remove all oil or grease. Oil or grease contamination from
compressed or bottled air can cause fi res in conjunction with oxygen.
For fi ltering, a coalescing fi lter able to fi lter to 0.01 microns should be placed as close as possible to the gas inlets
on the Gas Control Module.
Note 2: The tap water source does not need to be deionized, but in water systems with extremely high mineral
content a water softener is recommended. Tap water with high levels of particulate matter must be fi ltered.
Table 2-7: Gas Pressures, Flows, & Quality Requirements
2.10 Gas Applications
The customer will provide all gases and pressure regulators. Gases must be of high quality. Pressure regulators
shall be equipped with stainless-steel diaphragms and installed as close as possible to the Gas Console.
MATERIAL MILD STEEL STAINLESS STEEL ALUMINUM
OPERATION
GAS TYPE GAS TYPE GAS TYPE
PLASMA SHIELD PLASMA SHIELD PLASMA SHIELD
35-200 A Cut Air Air H35 N
2
H35 N
2
Table 2-8: Gas Applications
