INSTALLATION SHEET WET LOCATION WALL WASHERS
RGB Wall Washer
Command Setting Chart
Number Field 1 Number Field 2 Number Field 3
P 1- Static Red 1-9 Brightness Control
P 2- Static Green 1-9 Brightness Control
P 3- Static Yellow 1-9 Brightness Control
P 4- Static Blue 1-9 Brightness Control
P 5- Static Purple 1-9 Brightness Control
P 6- Static Cyan 1-9 Brightness Control
P 7- Static White 1-9 Brightness Control
P 8- All Color Jump - Warm to Cool 1-9 Speed Control
P 9- All Color Fade - Warm to Cool 1-9 Speed Control
P A- Random Color Fade 1-9 Speed Control
P B- Random Color Flashing 1-9 Speed Control
P C- Cycle All Modes 1-9 Speed Control
White Wall Washer
Command Setting Chart
Number Field 1 Number Field 2 Number Field 3
P 1- Sustain Light Option 1 1-9 Brightness Control
P 2- Sustain Light Option 2 1-9 Brightness Control
P 3- Sustain Light Option 3 1-9 Brightness Control
P 4- Sustain Light Option 4 1-9 Brightness Control
P 5- Sustain Light Option 5 1-9 Brightness Control
P 6- Sustain Light Option 6 1-9 Brightness Control
P 7- Sustain Light Option 7 1-9 Brightness Control
P 8- Random Light Jump 1-9 Speed Control
P 9- Pulse Fade 1 1-9 Speed Control
P A- Pulse Fade 2 1-9 Speed Control
P B- Random Strobe 1-9 Speed Control
P C- Cycle All Modes 1-9 Speed Control
