INSTALLATION INSTRUCTIONS
9520 and 9525 Instructions 9-24-12.doc
24 of 34
Section 10C: Reference –
Previous Model Year Ignition & Reverse Locations
Supplied
Interior
Harness
Model
Year
Function Connector
Dia.
Page
Location
Pin
Color
Color
F150
2004
Ignition
C270J
27
Right Kick
2
White /
L. Blue
Pink
Reverse
C270E
28
Right Kick
20
Black /
Pink
Green
F150
2005-
2008
Ignition
C270J
27
Right Kick
2
White /
L. Blue
Pink
Reverse
C270B
29
Right Kick
12
Green/
Yellow
Green
F150
2009-
2012
(early
production)
Ignition
C2280D
30
Right Kick
16
Blue or
Blue/
Red
Pink
Reverse
C215
31
Right Kick
6
Blue
Green
Super
Duty
2008
Ignition
C264
32
Right Kick SJB
10
Red /
Yellow
Pink
Reverse
C264
32
Right Kick SJB
12
Black /
Pink
Green
Super
Duty
2009-
2012
(early
production)
Ignition
C264
33
Right Kick
2
Blue
Pink
Reverse
C264
33
Right Kick
10
Green/
Blue
Green
