INSTALLATION
INSTRUCTIONS
9503 and 9504 Instructions 7-10-13.doc 1 of 12
950
Rear Vision System – Mirror Display
2007-2013 Chevrolet Silverado, Silverado HD; GMC Sierra, Sierra
HD (Kit part numbers 9002-9503, without comp/temp and 9002-
9504, with comp/temp)
Kit Contents:
Chassis Harness (longer)
Mirror Harness (shorter)
1 bubble bag containing:
Camera/Module/Bezel Assembly
Inside Rearview Mirror (ISRVM)
1 bag containing:
30 Wire Ties
1 Ground Nut
Anti-Corrosion Coating (in a white bottle)
Lock Plug
(optional)
Green 6’ Wire with 16-pin terminal
(optional)
1 bag containing:
Jumper Harness
1 bag containing:
Template (along with these instructions)
Tools Required:
Socket Wrench
10mm and 13mm Sockets
T15 and T20 Torx Bits
Torque Wrench
Plastic Trim Removal Tool
Phillips and Flat Blade Screwdrivers
Delphi Terminal Tool 12094429 or a small flat
blade watch repair screwdriver
Power Drill
25.4mm (1”) Hole Saw
29mm (1-1/8”) Hole Saw
Deburring Tool
Center Punch
Electrical Tape
Vehicle Hoist
Soldering Iron and Solder
(optional)
or T-taps
Note: We strive to provide accurate and up-to-date installation instructions. For the latest full
color instructions, as well as an installation video, please visit www.brandmotion.com
IMPORTANT: Before beginning kit installation:
• Verify kit contents are complete against list above.
• Please note that Kit 9002-9504, with comp/temp, requires purchasing a 9002-6008 kit (temperature
sensor harness). Refer to Kit 9002-9511 instructions posted on www.brandmotion.com for complete
installation procedure.
• Also note that vehicles without an auto dimming mirror require purchasing Brandmotion kit 9002-6105
(mirror harness) available separately. Please refer to Step 57 for installation details.
Preparation
1. Ensure all lamps and accessories are OFF.
2. Ensure ignition switch is in the OFF position.
3. Loosen negative battery cable bolt. Remove negative
battery cable from terminal and position away from
battery.
4. Wait one (1) minute prior to working on vehicle to
assure SIR roof rail airbag system has been disabled
for your safety.
