Brandmotion 9002-8524 - Manual

INSTALLATION
INSTRUCTIONS
8524 Instructions 7-18-13.doc 1 of 5
OEM Recessed Lip Camera with Harness and Slimline Mirror
(Kit part number 9002-8524)
Please read thoroughly before starting installation
and check that kit contents are complete.
Items Included in the Kit: Tools & Supplies Required:
Bubble bag containing:
Camera with Mount (in zip lock bag)
Camera Harness
Mirror
Chassis Harness
Zip lock bag containing:
12 Wire Ties
2 Rubber Well Nuts
2 Bolts
2 sets of T-taps
Zip lock bag containing:
These Instructions
Self-adhesive Template
T20 Torx Driver
Phillips Screwdriver
5/16” & 1/8” Drill Bits
Center Punch
Power Drill
Deburring Tool or Round File
Multi-meter or Computer Safe Test Light
Electrical Tape
Wire Crimper
Ground Eyelet
(Recommended)
Soldering Iron & Solder (Recommended)
Rust Inhibitor (Recommended)
Plastic Trim Removal Tool
Rubber Grommet or Silicone Caulk (Recommended)
Vehicle service manual (If needed)
Additional Parts That May Be Needed (see Application Guide. Parts sold separately):
5000-VWAB Volkswagen mirror mount adapter
5000-CAMLOCK Honda/ Subaru mirror mount adapter
Safety Precautions:
•
Work in well ventilated area that is clear of obstructions.
•
Secure vehicle with tire chucks in both front and rear of tires.
•
Turn vehicle accessories OFF and ensure ignition key is in OFF position.
•
Wear safety goggles and snug fitting clothes.
•
Use tools only for their intended purpose and which are in good repair.
•
Only perform this task if confidence, skill, and physical ability permit.
NOTE: We strive to provide accurate and up-to-date installation instructions. For the latest full color
instructions, as well as an installation video, (refer to relevant portions of the video for Kit # 9002-8530),
please visit www.brandmotion.com
