INSTALLATION INSTRUCTIONS
9527 Ford Flex Instructions 7-27-12.doc 1 of 18
Rear Vision System – Liftgate Emblem Camera Mirror Display
2009-2012 Ford Flex
(Kit part number 1008-9527)
Kit Contents: Tools Required:
Mirror
Liftgate Emblem Mount with Camera
Interior (shorter) Harness
Chassis (longer) Harness
2 Foam pieces (if needed and optional)
1 bag containing: Ford Emblem
1 bag containing:
2 Liftgate emblem retainers
2 Mounting Screws
1 bag containing:
25 Wire Ties (short)
7 pairs of T-taps (optional)
(Splice, solder & heat shrink recommended.)
Z-Tech (in a white bottle)
1 bag containing:
1 Template (along with these instructions)
2 Wire Ties (long and optional)
T15, T20, and T30 Torx Drivers
5.5mm, 7mm, 8mm, and 10mm Sockets
Flat Head Screwdriver
Phillips Screwdriver
Plastic Trim Removal tool
Pliers
Razor Knife or scissors
Wire Cutters
Soldering Iron
Small Brush
Addtional Tools:
Drill Bit
1¾ inch Center Hole Saw
Flat Metal File
Round File or Deburring Tool
Mirror Removal Tool # OTC8200
NOTE: We strive to provide accurate and up-to-date installation instructions. For the latest
full color instructions, as well as an installation video (use relevant portions of 1008-9520),
please visit www.brandmotion.com
PRE-INSTALLATION VEHICLE CHECKLIST
Before beginning, determine how the vehicle is equipped and check appropriate boxes:
Determine whether the vehicle has the required two mounting holes and a camera harness opening behind the existing
liftgate emblem. Refer to Steps 2-4 to remove inner liftgate panel, and use supplied 1008-9100-03 template to
confirm whether the required holes are present in the panel.
□
No, use supplied 1008-9100-03 template to position the holes to drill and/or cut the liftgate.
□
Yes, proceed to Section 2.
□
Vehicle has Sync microphone built into the rear view mirror (refer to Section 7). To retain Sync function,
Brandmotion Kit #5000-PESMVR external microphone must be installed.
□
Vehicle does NOT have an auto dimming inside mirror (refer to Section 8).
Determine the connector style used on the existing inside rearview mirror:
7-pin or 10-pin. For additional information, please see Section 6.
Determine the existing inside rearview mirror retention method:
T20 Torx screw or clip style. If clip style, the Mirror Removal Tool # OTC8200 (available from Brandmotion.com
and Ford dealers) or similar specialty tool, is required. For additional information, see Section 4.
□
Check kit contents are complete against the list above.
