INSTALLATION INSTRUCTIONS
9520 and 9525 Instructions 9-24-12.doc 2 of 34
TABLE OF CONTENTS
Pages
Section 1: Cut Pickup Bed Opening
(if required)
3
Section 2: Install Camera 4
Section 3: Modify Rain Sensor (if equipped) 5
Section 4: Remove Mirror 5
Section 5: Install Interior Harness 6-7
Section 6: Wire Interior Harness
6A: Remove compass circuit board (if required)
8
6B: Wiring for vehicles with 7-pin mirror connector 9
6C: Wiring for vehicles with 16-pin mirror connector 10
6D: Relocate compass circuit board
(if required)
11
Section 7: Wiring Required for Inside Mirrors without Auto
Dimming (if required)
12-16
Section 8: Install Supplied Mirror 17
Section 9: Install Chassis Harness 18-20
Section 10: Reference
10A: Supplied Harness Pinouts 21
10B: Previous Model Year Mirror Connector Pinouts 22-23
10C: Previous Model Year Ignition & Reverse Locations 24-31
10D: Relocating the Compass Circuit Board for
Vehicles with External Compass Module
(if required)
32-33
10E: Vehicles with Sync Microphone in Mirror ( if equipped)
34
