Rockwell Automation RECOMM-ENET EtherNet/IP Communications Module User Manual
Page 98

8-8
EtherNet/IP Communications Module
45
46
47
48
Gateway Act 1
Gateway Act 2
Gateway Act 3
Gateway Act 4
The value of each byte in the module’s current
gateway address. A value of “0” appears if the
module does not currently have a gateway
address.
49 EN Rx Overruns
The number of receive buffer overruns reported
by the Ethernet hardware.
50 EN Rx Packets
The number of Ethernet packets that the module
has received.
51 EN Rx Errors
The number of receive errors reported by the
Ethernet hardware.
52 EN Tx Packets
The number of Ethernet packets that the module
has sent.
53 EN Tx Errors
The number of transmit errors reported by the
Ethernet hardware.
54 Last TCP Reset
Last reason that the module reset or rejected a
TCP/IP connection.
55 Missed IO Pkts
Number of incoming I/O connection packets that
the module did not receive.
56 OPT Status
Operating status of optional I/O board (in External
Comms Kit).
57 OPT RX Errors
Number of optional I/O board receive errors.
58 OPT FW Version
Firmware version of optional I/O board (in
External Comms Kit).
Table 8.6 – Module Diagnostic Items (Continued)
No.
Event
Description
255 . 255 . 255 . 255
[Gateway Act 1]
[Gateway Act 2]
[Gateway Act 3]
[Gateway Act 4]
