Troubleshooting the Module and Network
8-11
21
Flt Cfg Error
Flt Cfg for the Reference or Datalinks is set to
a value greater than 65535 and the host
requires a 16-bit value.
22
App Updated
New application firmware detected.
23
EN Comm Flt
The module detected a communications fault
on the network.
24
EN Sent Reset
The module received a fault from the network.
25
EN Close Fit
An I/O connection from the network to the
module was closed.
26
EN Idle Flt
The module is receiving “idle” packets from the
network.
27
EN Open
An I/O connection from the network to the
module has been opened.
28
EN Timeout Flt
An I/O connection from the network to the
module has timed out.
29
PCCC IO Close
The device sending PCCC Control messages
to the module has sent the PCCC Control
Timeout to a value of zero.
30
PCCC IO Open
The module has begun receiving PCCC
Control messages.
31
PCCC IO Time Flt
The module has not received a PCCC Control
Message for longer than the PCCC Control
Timeout.
32
Watchdog T/O Flt
The software detects a failure.
33
EEPROM Init
A blank EEPROM map revision detected.
34
Normal Startup
The module completes a normal start up.
35
Manual Reset
The module was reset by changing parameter
20 (Reset Module).
36
EN Link Down
The Ethernet link was removed from the
module.
37
EN Link Up
An Ethernet link is available for the module.
38
BOOTP Response
The module received a response to its BOOTP
request.
39
Dup IP Addr
The module uses the same IP address as
another device on the network.
40
Peer IO Open
The module received the first Peer I/O image.
41
Peer IO Time Flt
The module has not received a Peer I/O
message for longer than the Peer I/O Timeout.
42
Email Failed
The module encountered an error attempting
to send a requested e-mail message.
Table 8.7 – Event Codes and Descriptions
Code
Event
Description
