Rockwell Automation RECOMM-ENET EtherNet/IP Communications Module User Manual
Page 154

C-18
EtherNet/IP Communications Module
4
Get
Number of
Components
BYTE
Number of components (e.g.,
main control board,
I/O boards) in the device.
5
Set
User Definable
Text
STRING[16]
Text identifying the device with a
user-supplied name.
6
Get
Status Text
STRING[12]
Text describing the status of the
device.
7
Get
Configuration
Code
BYTE
Identification of variations.
8
Get
Configuration
Text
STRING[16]
Text identifying a variation of a
family device.
9
Get
Brand Code
WORD
0x0002 = Reliance
11
Get
NVS Checksum
WORD
Checksum of the non-volatile
storage in a device.
12
Get
Class Revision
WORD
2 = DPI
13
Get
Character Set
Code
BYTE
1 = ISO 8859-1 (Latin 1)
2 = ISO 8859-2 (Latin 2)
3 = ISO 8859-3 (Latin 3)
4 = ISO 8859-4 (Latin 4)
5 = ISO 8859-5 (Cyrillic)
6 = ISO 8859-6 (Arabic)
7 = ISO 8859-7 (Greek)
8 = ISO 8859-8 (Hebrew)
9 = ISO 8859-9 (Turkish)
10 = ISO 8859-10 (Nordic)
255 = ISO 10646 (Unicode)
15
Get
Languages
Supported
STRUCT of
BYTE
BYTE[n]
Number of Languages
Language Codes (See Class
Attribute 2)
16
Get
Date of
Manufacture
STRUCT of
WORD
BYTE
BYTE
Year
Month
Day
17
Get
Product Revision
STRUCT of
BYTE
BYTE
Major Firmware Release
Minor Firmware Release
18
Get
Serial Number
DWORD
Value between 0x00 and
0xFFFFFFFF
19
Set
Language
Selected
BYTE
0 = Default (OIM will prompt at
start up)
1 = Language was selected (no
prompt)
Attribute
ID
Access
Rule
Name
Data Type
Description
