8-6
EtherNet/IP Communications Module
8.2
Module Diagnostic Items
Table 8.6 lists diagnostic items that can be accessed using
VS Utilities software or the LCD OIM. Diagnostic items can help you
or Rockwell Automation personnel troubleshoot communication
problems.
Table 8.6 – Module Diagnostic Items
No.
Event
Description
1
Common Logic
Cmd
The current value of the Common Logic
Command being transmitted to the host.
2
Prod Logic Cmd
The current value of the Product-Specific Logic
Command being transmitted to the host.
3
Reference
The current value of the Product-Specific
Reference being transmitted to the host.
4
Common Logic Sts The current value of the Common Logic Status
being received from the host.
5
Prod Logic Sts
The current value of the Product-Specific Status
being received from the host.
6
Feedback
The current value of the Product-Specific
Feedback being received from the host.
7
8
9
10
11
12
13
14
Datalink A1 In
Datalink A2 In
Datalink B1 In
Datalink B2 In
Datalink C1 In
Datalink C2 In
Datalink D1 In
Datalink D2 In
The current value of the specified Datalink being
transmitted to the host. (Value of 0 if datalink is
not used).
15
16
17
18
19
20
21
22
Datalink A1 Out
Datalink A2 Out
Datalink B1 Out
Datalink B2 Out
Datalink C1 Out
Datalink C2 Out
Datalink D1 Out
Datalink D2 Out
The current value of the specified Datalink being
received from the host.
23 DPI Rx Errors
The current value of the DPI Receive error
counter.
24 DPI Rx Err Max
The maximum value (since reset) of the DPI
Receive error counter.
25 DPI Tx Errors
The current value of the DPI Transmit error
counter.
26 DPI Tx Err Max
The maximum value (since reset) of the DPI
Transmit error counter.
