Rockwell Automation RECOMM-ENET EtherNet/IP Communications Module User Manual
Page 97

Troubleshooting the Module and Network
8-7
27 Boot Flash Count
The number of times the Boot flash segment has
been updated.
28 App Flash Count
The number of times the Application flash
segment has been updated in the field.
29 M-S Input Size
The size of data transferred from the network to
the drive.
30 M-S Output Size
The size of data transferred from the drive to the
network.
31
32
33
34
35
36
HW Addr 1
HW Addr 2
HW Addr 3
HW Addr 4
HW Addr 5
HW Addr 6
The decimal value of each byte in the module’s
Ethernet hardware address.
37
38
39
40
IP Addr Act 1
IP Addr Act 2
IP Addr Act 3
IP Addr Act 4
The value of each byte in the module’s current IP
address. A value of “0” appears if the module
does not currently have an IP address.
41
42
43
44
Subnet Act 1
Subnet Act 2
Subnet Act 3
Subnet Act 4
The value of each byte in the module’s current
subnet mask. A value of “0” appears if the module
does not currently have a subnet mask.
Table 8.6 – Module Diagnostic Items (Continued)
No.
Event
Description
255 : 255 : 255 : 255 : 255 : 255
[HW Addr 1]
[HW Addr 2]
[HW Addr 3]
[HW Addr 4]
HW Addr 5]
[HW Addr 6]
255 . 255 . 255 . 255
[IP Addr Act 1]
[IP Addr Act 2]
[IP Addr Act 3]
[IP Addr Act 4]
255 . 255 . 255 . 255
[Subnet Act 1]
[Subnet Act 2]
[Subnet Act 3]
[Subnet Act 4]
