Rockwell Automation GV3000/SE 230VAC 30-100HP GP & Vector Drive V6.04 Start-Up and Reference Manual User Manual
Page 85
3-9
Using the Keypad/Display To Program, Monitor, and Control the Drive
Table 3.3 describes the values that will be displayed when the corresponding
monitor mode LED is on.
Table 3.3 - Monitor Mode LEDs
Monitor Mode LED
SPEED
VOLTS
AMPS
HZ
KW
TORQUE
ALL LEDs
Corresponding Display When LED is ON (Actual Values)
Motor speed is displayed. This value is scaled in parameter
P.028.
Drive output volts are displayed. This value is not DC bus volts.
Drive output amps are displayed.
Drive output frequency in hertz is displayed.
Output power of the drive in kilowatts is displayed. Note that this
is intended for display purposes as a general indication of
kilowatt output and should not be used for control or exact
metering purpose.
Motor output torque is displayed in percent. (Valid only for
vector regulation).
Selected speed reference (in P.028 units) or torque reference (in
%) is displayed.
