3-8 GV3000/SE 230 VAC Drive, Software Reference Version 6.04
Meaning
Output power is being applied to the motor.
Output power is not being applied to the motor.
The drive is being controlled (START, RUN/JOG,
FORWARD/REVERSE, speed reference) from a source other
than the keypad.
The drive is being controlled from the keypad.
The network connection is lost.
Jog is selected.
Run is selected.
The drive is receiving its speed reference from the terminal
strip input or network option.
The drive is receiving its speed reference from the local
keypad or serial port (OIM or CS3000), i.e., using a manual
reference.
The requested motor direction is forward; the actual motor
direction is reverse (REVERSE LED is on).
The motor is running in the forward direction.
The motor direction is not forward.
The requested motor direction is reverse; the actual motor
direction is forward (FORWARD LED is on).
The motor is running in the reverse direction.
The motor direction is not reverse.
The keypad/display is in program mode.
The keypad/display is in monitor mode.
Parameters cannot be modified from the keypad without
entering the correct password into P.051 (Programming
Disable). See section 4.4, Ensuring Program Security, for
more information.
Note that disabling program changes by means of P.051 will
not prevent parameter changes being made from the serial
port or the network.
Parameters can be modified from the keypad.
STOP
RESET
LED
RUNNING
REMOTE
JOG
AUTO
FORWARD 1
REVERSE 1
PROGRAM
PASSWORD
Status
On
Off
On
Off
Flashing
On
Off
On
Off
Flashing
On
Off
Flashing
On
Off
On
Off
On
Off
1 If the speed reference is zero (0), pressing the FORWARD/REVERSE key (or toggling the FWD/REV
input) will not alter the state of the FORWARD or REVERSE LEDS.
If the drive is running (RUNNING LED is on), the STOP/RESET
key stops the drive. If the drive is not running (RUNNING LED is
off), pressing this key resets drive faults. Refer also the STOP/
RESET Key Disable Parameter (P.055).
3.6 Drive Status LEDs
The keypad contains eight LEDs that show the present drive status. Table 3.2
describes what each drive status LED means.
Table 3.2 - Drive Status LEDs
