I Table of Contents
C
ONTENTS
Preface .............................................................................................................................. VII
Chapter 1 Starting Up the Drive for Volts/Hertz Regulation
1.1
Preparing for Start Up (Volts/Hertz) ......................................................... 1-2
1.2 Start-Up Procedure (Volts/Hertz) ............................................................. 1-3
Chapter 2 Starting Up the Drive for Vector Regulation
2.1
Preparing for Start Up (Vector) ................................................................ 2-2
2.2 Start-Up Procedure (Vector) .................................................................... 2-3
Chapter 3 Using the Keypad/Display to Program, Monitor, and Control the Drive
3.1
Monitor Mode ........................................................................................... 3-2
3.1.1 Displaying the Selected Reference .............................................. 3-2
3.1.2 Entering the Manual Speed Reference ........................................ 3-3
3.2 Program Mode ......................................................................................... 3-3
3.3 Drive Control ............................................................................................ 3-4
3.4 The Display .............................................................................................. 3-4
3.4.1 Display Range .............................................................................. 3-4
3.4.2 Scaling the Manual Reference, Speed Display, and
Reference Display Using P.028 ................................................... 3-5
3.5 The Keypad .............................................................................................. 3-6
3.6 Drive Status LEDs ................................................................................... 3-8
Chapter 4 Programming Reference
4.1
Parameter Menus .................................................................................... 4-1
4.2 Parameter Types ..................................................................................... 4-2
4.3 Displaying or Changing Parameter Values ............................................. 4-3
4.4 Ensuring Program Security ...................................................................... 4-5
4.5 First Menu Parameters ............................................................................ 4-6
4.5.1 First Menu General Parameter Descriptions (P.000 to P.006) .... 4-6
4.6 Second Menu Parameters ....................................................................... 4-11
4.6.1 Entering the Second Menu Password .......................................... 4-11
4.6.2 Second Menu General Parameter Descriptions (P.007
to P.099) ..................................................................................... 4-14
4.6.3 Second Menu V/Hz Parameter Descriptions (H.000 to
H.022) ..................................................................................... 4-57
4.6.4 Second Menu Vector Parameter Descriptions (U.000 to
U.048) ..................................................................................... 4-70
Chaoter 5 Troubleshooting the Drive Using Error Codes
5.1
Identifying Alarm Codes and Recovering ................................................ 5-2
5.2 Identifying Fault Codes and Recovering ................................................. 5-3
5.3 Accessing, Reading, and Clearing the Faults in the Error Log ............... 5-6
5.4 Identifying Fatal Fault Codes and Recovering ........................................ 5-9
