Rockwell Automation GV3000/SE AC Drive 30-100HP, 230VAC V6.04 Hardware Ref, Install, Troubleshooting User Manual
Page 77
A-3
Technical Specifications
Table A.5 – Terminal Strip RS-232 Specifications
Signal Type
RS-232 Communications
Terminal(s)
1
2
3
Specification
XMIT
RECV
COMMON
Table A.6 – Encoder Feedback Device Specifications (FVC Regulation Only)
Specification
Motor Poles
Overcurrent IET
Overload Current Rating
Speed Control Range
Speed Control Response
Encoder Feedback
Service Factor
Rating
2, 4, 6, or 8 poles
200% load (based on drive nameplate
rating)
150% for 1 minute (based on drive
nameplate rating)
1:600 with 1024 PPR
15 Hz (typical)
15 V differential quadrature, encoder
incremental (512 PPR, 1024 PPR, 2048
PPR, 4096 PPR)
1.0
