3-2
GV3000/SE 230 VAC 30-100 HP Drive, Hardware Reference Version 6.04
3.1.2 Determining Total Area Required Based on Drive Dimensions
Drive dimensions and weights are listed in table 3.2. Overall drive dimensions are
illustrated in figure 3.1 as an aid in calculating the total area required by the
GV3000/SE drives.
Table 3.2 - Drive Dimensions and Weights
Condition
Operating Temperature (Ambient)
Storage Temperature (Ambient)
Humidity
Specification
0 ° to 55 ° C (32 ° to 131 ° F)
–40 ° to +65 ° C (–40 ° to +149 ° F)
5 to 95% (non-condensing)
• Be sure that drives are away from oil, coolants, or other airborne contaminants.
• Do not install the drive above 1000 meters (3300 feet) without derating output
power. For every 91.4 meters (300 feet) above 1000 meters (3300 feet), derate
the output current 1%.
• Verify that the drive location will meet the environmental conditions specified in
table 3.1.
Table 3.1 - Ambient Conditions
GV3000/SE
Drive
30V2060
50V2060
60V2060
100V2060
Dim. H1
544 mm
21.4"
714 mm
28.1"
Dim. H2
564 mm
22.2"
734 mm
28.9"
Dim. H3
504 mm
19.8"
674 mm
26.5"
Dim. H4
606 mm
23.9"
776 mm
30.6"
Dim. W
235 mm
9.3"
245 mm
9.6"
Dim. D
354 mm
13.6"
366 mm
14.4"
Weight
34 kg
75 lbs
44 kg
97 lbs
GV3000/SE
Drive
30V2060
50V2060
60V2060
100V2060
Dim. A1
10 mm
0.4"
10 mm
0.4"
Dim. A2
30 mm
1.2"
30 mm
1.2"
Dim. A3
10 mm
0.4"
10 mm
0.4"
Dim. A4
30 mm
1.2"
30 mm
1.2"
Dim. B1
51 mm
2.0"
51 mm
2.0"
Dim. B2
51 mm
2.0"
51 mm
2.0"
Dim. C1
100 mm
3.9"
200 mm
7.9"
Dim. C2
100 mm
3.9"
200 mm
7.9"
Dim. C3
9 mm
0.35"
9 mm
0.35"
Dia. d
9 mm
0.35"
9 mm
0.35"
