2-2
GV3000/SE 230 VAC 30-100 HP Drive, Hardware Reference Version 6.04
Table 2.1 - Power Ratings
Model
Number
30V2060
40V2060
50V2060
60V2060
75V2060
100V2060
Input Volts
(AC)
200-230 VAC
+/– 10%
200-230 VAC
+/– 10%
200-230 VAC
+/– 10%
200-230 VAC
+/– 10%
200-230 VAC
+/– 10%
200-230 VAC
+/– 10%
Input
KVA
41.8
53.8
59.8
77.7
97.6
109.6
Input Amps
(Maximum)
105 A
135 A
150 A
195 A
245 A
275 A
Output Amps
(Maximum) (1) (2)
105 A
135 A
150 A
195 A
245 A
275 A
Power Loss Watts
(Full Load)
660
900
1100
1350
1650
2250
(1) With vector regulation, 150% output current capability for one minute.
(2) These values are for operation with 4 kHz carrier frequency. For operation with 8 kHz carrier frequency, derating by 20% is required.
2.2 Enclosures
This manual describes GV3000/SE chassis style drives. These drives should be
installed in cabinets.
