3-5
Planning Before Installing
3.1.4 Verifying Power Module AC Input Ratings Match Supplied Power
It is important to verify that plant power will meet the input power requirements of
the GV3000/SE drive's Power Module circuitry. Refer to table 2.1 for input power
rating specifications. Be sure input power to the drive corresponds to the drive
nameplate voltage and frequency.
3.2 Wiring Requirements for the Drive
Certain drive requirements should be checked before continuing with the drive
installation. Wire sizes, branch circuit protection, speed feedback (for FVC
regulation), and E-stop wiring (see chapter 7), are all areas that need to be
evaluated.
3.2.1 Meeting Terminal Strip Input and Output Specifications
The terminal strip on the Regulator board provides terminals for 24 VDC power for
the eight remote control inputs. Refer to tables A.3 and A.4 for control input and
output specifications.
3.2.2 Determining Wire Size Requirements
Wire size should be determined based on applicable local, national, and
international codes (e.g., NEC/CEC regulations).
ATTENTION: The user is responsible for conforming with all
applicable local, national, and international codes. Failure to observe
this precaution could result in damage to, or destruction of, the
equipment.
3.2.2.1 Recommended Power Wire Sizes
Input power wiring should be sized according to applicable codes to handle the
drive's continuous-rated input current. Output wiring should be sized according to
applicable codes to handle the drive's continuous-rated output current. See tables
3.3 and 3.4 for recommended power wire sizes.
Important: Use only copper (Cu) wire with a temperature rating of 60/75 ° C.
Table 3.3 - Recommended Power Wire Sizes for 30 to 50 HP Drives
!
Type of Wiring
AC Input Power
Output Power
DC Input Power
Terminals
R/L1, S/L2, T/L3
U/T1, V/T2, W/T3
P, N
Size of Wire (Maximum)
3/0 AWG (or 85 mm 2 )
