4-3
Mounting the Drive, Grounding, and Finding Wire Routing Locations
Figure 4.1 - Terminal Locations
GND
U&W
U
V
W
R S T P N P, N R S T
U V W GND
V
Terminals:
R, S, T: Drive input power terminals
U, V, W: Drive output power terminals
P (+), N (–): DC bus terminals
GND: Ground terrminal
FRONT VIEW
BOTTOM VIEW
