3-9
Planning Before Installing
AC reactor must be installed in the AC input line. Tables 3.9 and 3.10 show
selection values for the circuit breakers and AC reactors respectively.
Table 3.9 - Circuit Breaker Selection Values
Table 3.10 - AC Reactor Selection Values
Model Number
30V2060
40V2060
50V2060
60V2060
75V2060
100V2060
Horsepower Rating
30 HP
40 HP
50 HP
60 HP
75 HP
100 HP
Circuit Breaker
Rating
150 A
200 A
250 A
300 A
350 A
400 A
Model Number
30V2060
40V2060
50V2060
60V2060
75V2060
100V2060
Horsepower Rating
30 HP
40 HP
50 HP
60 HP
75 HP
100 HP
AC Reactor
LS3-125/3-1
(125 A/84 mH)
LS3-160/3-1
(160 A/66 mH)
LS3-160/3-1
(160 A/66 mH)
LS3-200/3-1
(200 A/54 mH)
LS3-250/3-1
(250 A/42 mH)
LS3-300/3-1
(300 A/36 mH)
3.2.4 Meeting Encoder Specifications (FVC Regulation Only)
GV3000/SE drives set up for FVC regulation require an encoder for closed loop
operation. Encoder specifications are provided in table A.6. Drives set up for V/Hz
or SVC regulation do not require an encoder for feedback because they operate in
open loop mode.
3.2.4.1 Encoder Wiring Guidelines
Encoder connections are considered signal level wiring and, therefore, must be run
separate from control and power wiring. Reliance Electric recommends 18 AWG
unshielded twisted pair wires with 2-3 twists per inch for applications to a maximum
distance of 303 meters (1000 feet). The recommended Reliance Electric part
number is 417900-207CG, 18 AWG, 6 conductor (3 twisted pairs).
3.2.5 Verifying Power Module Output Current Rating is Greater Than
Motor Full Load Amps
Verify that the GV3000/SE output current rating is greater than the motor's full load
current (amps). Table 2.1 lists the output current values.
