Rockwell Automation GV3000/SE AC Drive 30-100HP, 230VAC V6.04 Hardware Ref, Install, Troubleshooting User Manual
Page 20
2-6
GV3000/SE 230 VAC 30-100 HP Drive, Hardware Reference Version 6.04
Figure 2.4 - Regulator Board Components and Locations
USER DISPLAY
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
34-Pin Ribbon Cable
J3
J8
J7
J17
J4
USER I/O TERMINAL STRIP
J9
J5
26-Pin Ribbon Cable
J3 - Option Board Connector
J4 - Analog Input Jumper
J5 - Power Module Feedback Cable
J7 - OIM (optional) Connector
J8 - RS232C Port
J9 - Keypad/Display Connector
J17 - Analog Output Jumper
