Rockwell Automation 1440-TTC06-00RE XM-362 Temperature Module User Manual
Page 99

Publication GMSI10-UM008D-EN-P - August 2010
91
Instance 199 - Dynamic Assembly
This Assembly instance can be created and configured with the XM Serial
Configuration Utility or RSMACC Enterprise Online Configuration Utility.
Using the configuration software, you determine the format of the data. This
assembly instance can be selected to be sent in response to an I/O Poll request
from a Master.
The dynamic Assembly can include all of the measurement values included in
Assembly instance 101. In addition, the dynamic Assembly can include the
following configuration parameters.
28 - 31
Channel 4 Rate of Change value
32 - 35
Channel 5 Temperature Measurement value
36 - 39
Channel 5 Rate of Change value
40 - 43
Channel 6 Temperature Measurement value
44 - 47
Channel 6 Rate of Change value
48 - 51
Channel 1 - Channel 6 Difference
52 - 55
Channel 2 - Channel 1 Difference
56 - 59
Channel 3 - Channel 2 Difference
60 - 63
Channel 4 - Channel 3 Difference
64 - 67
Channel 5 - Channel 4 Difference
68 - 71
Channel 6 - Channel 5 Difference
Table C.13 Instance 103 Data Format (Measurement Values Assembly)
Byte
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
Table C.14 Instance 199 Component Mapping
EPATH (where ii =
instance number)
Class
Name
Class
Number
Instance
Number
Attribute
Name
Attribute
Number
Data
Type
21 1D 03 24 ii 30 04
Alarm
31D
h
1 - 18
Alarm Enable
4
BOOL
21 1D 03 24 ii 30 07
Alarm
31D
h
1 - 18
Condition
7
USINT
21 1D 03 24 ii 30 08
Alarm
31D
h
1 - 18
Alert Threshold (High)
8
REAL
21 1D 03 24 ii 30 09
Alarm
31D
h
1 - 18
Danger Threshold
(High)
9
REAL
21 1D 03 24 ii 30 0A
Alarm
31D
h
1 - 18
Alert Threshold Low
10
REAL
21 1D 03 24 ii 30 0B
Alarm
31D
h
1 - 18
Danger Threshold Low 11
REAL
21 1D 03 24 ii 30 0C
Alarm
31D
h
1 - 18
Hysteresis
12
REAL
21 23 03 24 ii 30 04
Relay
323
h
1 - 8
Relay Enable
4
BOOL
21 23 03 24 ii 30 05
Relay
323
h
1 - 8
Latch Enable
5
BOOL
21 23 03 24 ii 30 06
Relay
323
h
1 - 8
Failsafe Enable
6
BOOL
