Publication GMSI10-UM008D-EN-P - August 2010
62
Data Parameters
The Data parameters are used to view the measured values of the input
channels and the 4–20 mA outputs, as well as to monitor the status of the
channels, alarms, and relays.
Channel Data Parameters
TIP
To view all the data parameters in the XM Serial
Configuration Utility, click the View Data tab.
Channel Data Parameters
Parameter Name
Description
Values/Comments
Channel Status
States whether a fault exists on the associated
channel. If a fault exists, the measurement and rate
of change values may not be accurate.
Possible status values: No Fault
Fault
Shows the current measurement value for the
channel.
Important: Channel 6 data values are
not available if the Enable relay
reset switch terminals is enabled.
(Refer to General Parameters on page
48.) The Channel 6 measurement
Value will display "Open" if the
measurement value is <0.5, or
"Closed" if the measurement value is
≥ 0.5.
Shows the current rate of change value for the
channel.
Difference
Shows the current difference value for the channel.
This value is calculated by subtracting the previous
channel's measurement from this channel’s
measurement.
Cold Junction Temperature (XM
Serial Configuration Utility only)
Shows the temperature at the module’s terminal
block junction.
Cold Junction Status (XM Serial
Configuration Utility only)
Shows the cold junction status.
Possible status values: Overrange
Underrange
No Fault
XM Configuration
Utility
EDS File
Value
Measurement
Value
XM Configuration
Utility
EDS File
Rate
Rate of
Change
