The Poll response data can also be requested explicitly through Assembly
Object (Class ID 0x4), Instance 101 (0x65) – 103 (0x67), Data Attribute (3).
The following tables show the static data format of Assembly instance 101–
103.
XM-361/362 Assembly Instance 101 Data Format
Byte
Definition
0–3
Channel 1 measurement value
4–7
Channel 2 measurement value
8-11
Channel 3 measurement value
12-15
Channel 4 measurement value
16-19
Channel 5 measurement value
20-23
Channel 6 measurement value
24-27
Channel 1 rate of change value
28-31
Channel 2 rate of change value
32-35
Channel 3 rate of change value
36-39
Channel 4 rate of change value
40-43
Channel 5 rate of change value
44-47
Channel 6 rate of change value
XM-361/362 Assembly Instance 102 Data Format
Byte
Definition
0–3
Channel 1 rate of change value
4–7
Channel 2 rate of change value
8-11
Channel 3 rate of change value
12-15
Channel 4 rate of change value
16-19
Channel 5 rate of change value
20-23
Channel 6 rate of change value
24-27
Channel 1 measurement value
28-31
Channel 2 measurement value
32-35
Channel 3 measurement value
36-39
Channel 4 measurement value
40-43
Channel 5 measurement value
44-47
Channel 6 measurement value
