Publication GMSI10-UM008D-EN-P - August 2010
88
Instance Attributes
Assembly Instance Attribute Data Format
Instance 100 - Alarm and Relay Status
This assembly is sent using COS messaging when any of the Alarm or Relay
Status values change.
101
Default Poll Response
Message
Input
Measurement values
102 - 103
Alternate Poll Response
Message
Input
Measurement values
199
Alternate Dynamic Poll
Response Message
Input
User configurable
measurement values and
configuration parameters
Table C.8 Assembly Object Instances
Instance
Name
Type
Description
Table C.9 Assembly Object Instance Attributes
Attr ID
Access
Rule
Name Data
Type
Value
1
Get
Number of Members in list
UINT
Only supported for Dynamic Assembly
instance
2
Set
Member List
Array of STRUCT:
Only supported for Dynamic Assembly
instance
Member Data Description
UINT Size of member data value in bits
Member Path Size
UINT
Member Path
Packed EPATH
3
Get
Data
Defined in tables
on the following
pages.
Table C.10 Instance 100 Data Format (Alarm and Relay Status Values Assembly)
Byte
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
0
Relay 1
Status
0
Alarm 2 Status
(Channel 2 value)
Alarm 1 Status
(Channel 1 value)
1
Relay 2
Status
0
Alarm 4 Status
(Channel 4 value)
Alarm 3 Status
(Channel 3 value)
2
Relay 3
Status
0
Alarm 6 Status
Channel 6 value)
Alarm 5 Status
(Channel 5 value)
