Rockwell Automation 1440-TTC06-00RE XM-362 Temperature Module User Manual
Page 97

Publication GMSI10-UM008D-EN-P - August 2010
89
Instance 101 - Measurement Values
This assembly instance can be selected to be sent in response to an I/O Poll
Request from a Master. This instance is the default Poll response selection.
3
Relay 4
Status
0
Alarm 8 Status
(Channel 2 rate)
Alarm 7 Status
(Channel 1 rate)
4
Relay 5
Status
0
Alarm 10 Status
(Channel 4 rate)
Alarm 9 Status
(Channel 3 rate)
5
Relay 6
Status
0
Alarm 12 Status
(Channel 6 rate)
Alarm 11 Status
(Channel 5 rate)
6
Relay 7
Status
0
Alarm 14 Status
(Channel 2 difference)
Alarm 13 Status
(Channel 1 difference)
7
Relay 8
Status
0
Alarm 16 Status
(Channel 4 difference)
Alarm 15 Status
(Channel 3 difference)
8
0
0
Alarm 18 Status
(Channel 6 difference)
Alarm 17 Status
(Channel 5 difference)
Table C.10 Instance 100 Data Format (Alarm and Relay Status Values Assembly)
Byte
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
Table C.11 Instance 101 Data Format (Measurement Values Assembly)
Byte
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
0 - 3
Channel 1 Temperature Measurement value
4 - 7
Channel 2 Temperature Measurement value
8 - 11
Channel 3 Temperature Measurement value
12 - 15
Channel 4 Temperature Measurement value
16 - 19
Channel 5 Temperature Measurement value
20 - 23
Channel 6 Temperature Measurement value
24 - 27
Channel 1 Rate of Change value
28 - 31
Channel 2 Rate of Change value
32 - 35
Channel 3 Rate of Change value
36 - 39
Channel 4 Rate of Change value
40 - 43
Channel 5 Rate of Change value
44 - 47
Channel 6 Rate of Change value
48 - 51
Channel 1 - Channel 6 Difference
52 - 55
Channel 2 - Channel 1 Difference
56 - 59
Channel 3 - Channel 2 Difference
60 - 63
Channel 4 - Channel 3 Difference
64 - 67
Channel 5 - Channel 4 Difference
68 - 71
Channel 6 - Channel 5 Difference
